Description
Features
| Inner tube | Reinforcement | Cover |
|---|---|---|
| Polyester elastomer | One or two braids of synthetic fiber | Polyurethane, lime green, laser branding |
| Description |
|---|
| Applications for compact sewer cleaning vehicles and equipment for cleaning residential, commercial and industrial lateral sewer lines connected to the main sewer line. Features including lightweight and extremely flexible – Kink resistant – One or two polyester braid reinforcement – Thicker lime green cover designed to withstand humid environments, ensuring extended service life and enhanced wear resistance. Hose suitable for lateral sewer cleaning applications requiring very high pressure performance and high flexibility for cleaning smaller sewer pipes. |
| Temperature range |
|---|
| -40°C to +60°C (-40°F to +140°F) |
Technical Details
| Part no. | Hose size (dash) | Hose size (inch) | Hose size (DN) | ID (mm) | OD (mm) | WP (psi) | BP (psi) | Safety factor | Bend radius (mm) | Weight (g/m) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1191 | -3 | 3/16” | 5 | 5.0 | 10.4 | 4000 | 12000 | 3:1 | 25 | 75 |
| 1192 | -4 | 1/4” | 6 | 6.5 | 12.9 | 4000 | 12000 | 3:1 | 35 | 115 |
| 1194 | -6 | 3/8” | 10 | 9.7 | 17.5 | 4000 | 12000 | 3:1 | 45 | 190 |
| 1195 | -8 | 1/2” | 12 | 13.0 | 23.2 | 4000 | 12000 | 3:1 | 70 | 325 |
